Precision Mechanism & Multi-Part Assembly

Kinematic Linkage & Tolerancing Analysis:

Mechanical design and 3D CAD development of a stapler assembly, integrating the main body, magazine, staple-driving mechanism, hinge components, spring elements, and supporting mechanical parts into a complete functional assembly.

Key Engineering Highlights:

• Complete 3D CAD modeling of the stapler assembly.
• Mechanical development of the main body and staple magazine.
• Integration of the staple-driving mechanism and hinge components.
• Spring and moving-component integration within the assembly.
• Component positioning, clearances, and mechanical relationships.
• Assembly development with consideration of practical manufacturing.
• Engineering documentation generated from the completed CAD model.
